Wall Frames
Wall Frames
Emcee Truss & Frame Wall Frames - Key Advantages:
High quality built by a qualified tradesman
Computer aided manufacture
Full computations for timber components, bracing and tie downs
The Multinail Steel Nog system
is designed to replace
timber nogs
.
Benefits of galvanised steel nogs:
Lighter & easier to handle, reducing the weight of frames by removing timber nogs.
Better accessibility, making it easier to run electrical & plumbing in wall cavity area.
Easy installation of insulation.
Frames are more ridged & square.
Simple to add extra power points etc. after plaster.
Elimates bowing of end stud.
Application:
Two individual rows of steel nogs are required to replace a single row of timber nogs
Maximum rebate depth at stud 10mm.
Fix to first and last studs with 2/2.50 hardened screw shank gun nails.
Fix remaining studs with 1/2.50 hardened screw shank gun nails
Maximum wall height of 3m
Design studs as per AS1684.
All jobs come with own certification.
